Whether you are carrying out a construction project, developing the business premises, or making a major improvement to your property, it is imperative that you know the legal boundaries and the physical boundaries too. A boundary and topographic survey is a single report that combines the two essential surveying services, giving architects, engineers, developers, contractors, and property owners the accurate information they require to design, permit, and build with confidence.

Professional combined survey services for residential, commercial, industrial, and municipal projects in South Florida by Core Action Group, LLC. A detailed boundary survey and a topographic survey also allow us to save our clients time and make their project planning easier and less time-consuming, as they will not have to visit the site more than once. The result is a comprehensive survey that outlines the boundaries of the property and records any existing elevations, terrain, utilities, structures, drainage systems, or site conditions that could affect the design and construction.

From a new commercial development to a residential addition to a South Florida engineering survey, our team has the expertise to provide you with accurate and reliable survey information to meet your project requirements. Whether you’re developing a site, applying for permits, or planning the construction of a project, our surveys have the information you need to get things moving forward with confidence.

What Is A Boundary & Topographic Survey-img

What Is A Boundary & Topographic Survey?

A boundary and topographic survey is a combined survey service of two items that are needed in one report. The boundary portion defines the legal boundaries of the property, and the topographic portion represents existing physical features and changes in elevation on the property.

A boundary survey establishes boundary lines, verifies boundary dimensions, determines the position of corner stakes, and establishes the relationship of the property to surrounding properties. It also helps detect any encroachments, checks setbacks, and provides exact information for future building or development.

The topographic portion includes natural and man-made features of the property. Our team employs cutting-edge surveying technology to gather accurate elevation data and map the site’s topography, providing a comprehensive view of the existing condition.

Many clients decide to have a boundary survey + topo survey combo for a single project so that all of the information required for project planning, engineering, permitting, and construction is coordinated. This will cut down on duplication, increase efficiency, and allow everyone involved in the project to use the same up-to-date and correct data set

When Do You Need Both A Boundary & Topo Survey?

Many projects require more than simply identifying property lines. Engineers or architects must also know the site’s topography, contours, drains, and buildings before they can start making plans to improve it. That’s why many property owners decide not to order separate services and opt for a combined survey.

Site Development Projects

Before engineering plans are prepared or permit applications submitted, the information required is obtained through a survey for site development. Combined surveys help developers to understand legal boundaries on the property and the physical features before embarking on design work for commercial residential communities, offices, and mixed-use projects.

Civil Engineering Projects

A civil engineering survey supplies engineers with the information they need to create infrastructure changes, utility plans, roadway designs, compliance with industry standards, and stormwater arrangements. The boundary + topographic survey done by our professional team provides the engineers with detailed terrain mapping, elevation data, and site features of any existing site.

Drainage Improvements

When designing drainage improvements, it is important to understand the flow of water on a property. A topographic survey provides you with all the necessary information needed for drainage analysis so that engineers can easily determine the low points, drainage paths, and grading problems before the work is begun.

Grading Plans

Accurate topographic information is important for many developers and engineers when initiating and creating a grading plan. Existing elevations can assist engineers in getting a better estimate of the amount of earthwork operations needed for the job and in providing adequate drainage and stability of the site.

Permit Applications

Many municipalities will want a permit survey before you consider making any development plans. A combined survey is what you need that can provide accurate boundary and topographic data to support and assist in zoning consideration, engineering, and building approvals, which would be much easier to get.

Property Redevelopment

Representing redevelopment of an existing commercial property can be complex. Existing buildings, utilities, parking lots, or drains need to be properly documented before developing improvements are designed. With a commercial development survey, property owners and design teams have the data they need to ensure compliance.

Who Orders Combined Surveys?

A boundary and topographic survey can be used by a variety of professions that require data related to the development of land, construction, infrastructure, and property management. The survey also incorporates detailed site conditions and is used as one of the first documents in project planning as a result of the legal boundary information.

Property Developers

The combined survey services are used by the developer before buying land, making development plans, and starting construction. Survey details enable the proper assessment of the site to be developed and the identification of any site constraints that could impact design.

Civil Engineers

Combined surveys are performed by engineers to create grading plans, stormwater systems, utility plans, roadways, and other infrastructure changes. Elevation data, terrain mapping, and boundary information are essential to minimize design conflicts and errors and enhance project accuracy.

Architects

The architects must have the correct data to place buildings, check setbacks, coordinate parking layout, and design according to the existing site. This is the base information we will use throughout the design process and can be combined into a survey.

Contractors

During construction planning, general contractors conduct surveys to verify the location of buildings, recognize the existing grades, and coordinate with project engineers and architects. The precise survey data minimizes changes on site once the building process has started.

Municipalities

Public agencies often need the data from a development survey for infrastructure, roadway improvements, parks, and utility installation. The collection of site information through a combined survey guarantees that public projects are designed with the most up-to-date and accurate information.

Utility Companies

Utility companies may need specific survey data prior to the installation of new underground or overhead utilities. Engineers and contractors use existing site features and elevations to coordinate the design of utilities and reduce potential conflicts with existing improvements.

What Is Included In A Combined Survey Report?

It is so much more than a sketch of the property. It fuses legal boundary data with detailed site data and makes it available to architects, engineers, developers, contractors, and property owners to support informed decision-making during the planning and building process. Core Action Group, LLC prepares a combined survey report with accuracy and attention to detail. The extent of reports can range from property to property and project to project; however, we try to give you a full overview of the property’s legal boundaries, as well as the existing site conditions.

Boundary Information

This boundary survey will usually contain:

  • Property boundary lines
  • Boundary dimensions
  • The corners and corner stakes of the property.
  • Existing survey monuments
  • Rights of way and easements (if applicable)
  • Visible encroachments
  • Nearby streets and entrances
  • Fences and walls are in place around the property lines
  • Placement of facilities in relation to the boundaries
  • Compliance with setback requirements (as requested)

Topographic Information

  • Existing ground elevations
  • Finished floor elevations
  • Buildings and structures
  • Sidewalks
  • Parking lots
  • Curbs
  • Driveways
  • Retaining walls
  • Utility structures
  • Storm drains
  • Drainage swales
  • Water features
  • Existing pavement
  • Surface improvements

The data is used to make a detailed contour map that indicates changes in elevation on the property, which can be used to help engineers determine how water moves through the site.

Boundary & Topographic Survey Process

These surveys are done in a systematic manner at Core Action Group, LLC to ensure that each one is accurate, complete, and customized to the needs of your project.

Initial Consultation

Each project starts with a discussion of your objectives, property, and intended uses of the survey. We understand the scope of work you need for a site development survey, permit, or commercial development survey, and decide on the information you need for your project.

Records & Boundary Research

Our company inspects and analyzes all available deeds, subdivision plats, previous surveys, easements, and public records to determine the legal dimensions of the property. This research will serve as the basis for verifying the boundaries accurately and in compliance before fieldwork.

Field Survey

Our field crews take accurate survey readings throughout the property with GPS, robotic total stations, and other surveying technology. Corner stakes and visible encroachments are identified, structures and utilities are mapped, and elevation data is collected on the topographic area of the survey.

Data Processing & Mapping

After fieldwork is finished, the data gathered is handled and analyzed to make an exact digital replica of the estate. The survey data is used to create a detailed contour map, to prepare a boundary mapping, and to confirm site conditions that are required.

Quality Review

All surveys are carefully reviewed prior to delivery to ensure accuracy, consistency with applicable standards, and that all requested information is included. We verify each legal boundary, which provides reliable survey information for effective planning, design, permitting, and construction in South Florida.

Deliverables: Plat, Contour Map, CAD Files

Core Action Group, LLC offers boundary topographic survey in South Florida whose deliverables can be easily incorporated into engineering, architectural, and construction processes, making us the leading choice for your land surveys.

Survey Plat

The completed survey plat provides a detailed illustration of the property's legal boundaries, dimensions, improvements, and other features identified during the survey. This legally recognized document is essential for project planning, permit applications, financing reviews, and long-term property records. Architects, engineers, contractors, and permitting authorities all rely on this drawing throughout the project lifecycle.

Contour Map

The contour map visually represents your site's elevation changes, terrain features, and drainage patterns across the entire property. Engineers and architects use this data to make informed decisions about grading, drainage, and building placement. It directly supports site grading, drainage improvements, building placement, roadway design, utility planning, and stormwater management throughout the design and permitting process.

CAD Deliverable

Our surveys are delivered as AutoCAD-compatible (.dwg) and Civil 3D files, allowing project teams to begin design work immediately without recreating survey data from scratch. Each CAD file integrates directly into existing design software, facilitating better coordination between surveyors, engineers, architects, and contractors while reducing project timelines and minimizing the risk of design errors.

Elevation Reference System

All elevation data is referenced to NAVD88 (North American Vertical Datum of 1988), providing a consistent vertical control system for engineering and construction projects. This standardized datum ensures full compatibility with Broward County and Palm Beach County government requirements, FEMA flood zone determinations, civil engineering design workflows, and infrastructure planning across South Florida.

Combined Survey Cost In South Florida

The boundary and engineering survey in South Florida will vary for each project due to the uniqueness of every property. Core Action Group, LLC does not have a fixed price or rate as we customize quotes for the scope of work required.

Some of the factors that can affect project costs are:

  • Property size and acreage
  • Site accessibility
  • Terrain complexity
  • Existing vegetation
  • Number of structures on the property
  • Availability of previous survey records
  • The amount of elevation information needed
  • Density of improvements
  • Utility features
  • Complexity of boundary research
  • Required level of detail
  • Digital deliverable requirements
  • Project timeline
While it’s true that a combination of services will be more expensive than ordering one survey, a boundary survey + topo survey combo is often less expensive than ordering separate surveys at various stages of a project. Having the necessary information gathered in a single site visit also minimizes duplication, communication issues, and project inefficiency.

Request A Combined Survey Quote

Accurate information is the first step to successful development. A boundary and topographic survey can help you proceed confidently, as Core Action Group, LLC provides complete combined survey services that save property owners and project teams time. It also helps to coordinate design and construction and minimize the “surprise” that becomes a barrier. Our surveys can be used at any stage of development, from precise boundary verification to detailed topographic mapping.

Ready to get started? Call Core Action Group, LLC at 954-743-9363 or fill out the form below. Tell us about your property and project requirements and we’ll follow up with a customized quote – no obligation.

FAQs

A boundary survey determines the legal boundaries of your property, establishes property corners, and verifies setbacks and possible encroachments. A topographic survey is a mapping of the physical features of the land, such as elevation, terrain, utilities, drainage features, buildings, and vegetation. For design and construction, both services will be combined to get the complete knowledge about your property.
The boundary and topographic survey is requested by land investors, commercial property owners, municipalities, contractors, civil engineers, architects, and developers. These surveys are critical for site development, infrastructure, and commercial construction.
Combination survey reports will usually provide an existing building map, a map of the property boundaries, corner stakes, visible encroachments, utilities, drainage, terrain elevations, and a detailed contour map. This may also be used to assist with grading plans, drainage analysis, and permit applications, depending on project needs.
Yes. We can deliver a CAD version of the survey that can be directly added to architects, engineers, and design professionals’ design software. The use of digital files can simplify project work planning and eliminate any further drafting.
The time frame will vary depending on the size, complexity, access, and project needs of the property. Depending on the size of the site and the amount of data processing required, it can take several business days to finish the smaller sites or several weeks for larger commercial properties or developments where extensive fieldwork and data processing are required.

Service Areas - Broward & Palm Beach County

Core Action Group, LLC proudly provides boundary and topographic survey Broward County and boundary and topographic survey Palm Beach County services for developers, engineers, architects, contractors, municipalities, and property owners across South Florida. We regularly complete boundary topo survey Fort Lauderdale, boundary topographic survey Hollywood FL, and boundary topo survey West Palm Beach projects for residential, commercial, industrial, and mixed-use developments. Whether you require a combined survey in South Florida for site planning, permitting, engineering design, or construction, our experienced team delivers accurate survey data tailored to your project’s unique requirements.
